T44-36

MATERIAL 36 (Permeabilität 75)

-26- & 36 Material: Ein sehr populäres Material, es ist ein kostengünstiges Allzweckmaterial, das in einer Vielzahl von Stromumwandlungs- und Netzfilteranwendungen nützlich ist.

Ein wasserstoffreduziertes Eisenmaterial, das Material '41' sehr ähnelt, aber einen erweiterten Frequenzbereich bietet.

50/60Hz - bis 500 kHz für Leistungsan

Bevorzugte Anwendungsbereiche:
Licht-Dimmer-Drosseln 50/60 Hz,

EMI-Netz Drosseln

DC-Drosseln <50 kHz

Leistungsfaktor-Korrektur Drosseln <50 kHz.

Kern

Farbe

Außen

mm

Innen

mm

Höhe

mm

Perme-abilität



AL (nH/100Wdgg.2)

AL-Toleranz

Frequenz-bereich

Mass

(approximate)

Product Group

T44-36

weiß/gelb

11,18

5,82

4,04

µ 70

370

±10%

DC-1 MHz

1,9

gramm

PC



AL value (nominal)

37 nH/ N²

Test Winding

N=100, #34 AWG

Frequency

10 kHz

Voltage on Agilent 4284A

0.044V

Coating Type

white/yellow Epoxy Paint

Voltage Breakdown (min.)

500 Vrms, 60Hz

Limit

0.1 mA, 5 s

Density gm/cm3

7





Magnetic

Dimen-

sions

Le Eff. Mag. Path Length (cm)

Ae

Eff. Mag. Cross Section (cm2)

Veff Eff. Core Volume (cm3)

WA - Min. Eff. Window Area

sa - Surface Area

mlt - mean length per turn

2.68 cm

0.0990 cm²

0.266 cm³

0.221 cm²

4.81 cm²

1.81 cm



Core Loss

Bpk

140 G

frequency

100 kHz

Core Loss (nominal)

83 mW/cm³



Core Loss (maximum)

95 mW/cm³

where Bpk expressed in gauss, f expressed in hertz, and:

a=1.00E+09, b=1.10E+08, c=1.90E+06, d=1.90E-13



DC Saturation

HDC

50 Oe

Percent Initial Perm (nom.)

55.2%

Percent Initial Perm (min.)

47.4%

where H expressed in oersteds, and:

a=1.00E-02, b=9.70E-06, c=1.72, d=0.00



Wire

Size

AWG

18

20

22

24

26

28

30

32

34

36

38

mm

1.000

0.800

0.630

0.500

0.400

0.315

0.250

0.200

0.160

0.125

0.100

Single

Layer

Turns

11

14

18

23

29

37

47

59

74

93

116

RDC(Ω)

4.2m

8.4m

17.3m

35.1m

70.3m

142.7m

288.3 m

575.7m

1.1

2.3

4.6

Full

Winding

Turns

10

16

25

38

59

91

141

219

339

524

812

RDC(Ω)

3.8m

9.6m

24.0m

58.0m

143.1m

351.0m

865.0m

2.1

5.3

12.9

31.9

T44-52



-52 Material: Dieses Material hat geringere Kernverluste bei hoher Frequenz und die gleiche Durchlässigkeit wie das -26 und -36  Material. Es ist beliebt für Hochfrequenz-Choke-Designs und in einer Vielzahl von Geometrien verfügbar.

‐52 Material: This material has lower core losses at high frequency and the same permeability as the ‐26 and -36 Material. It is popular for high frequency choke designs and available in a wide variety of geometries.

Material 52 (Permeabilität 75)

50/60 Hz- Differential mode EMI Line-Chokes

z.B.350 µ H -100 Umdrehungen=35,0nH/N²

IRON POWDER TOROIDAL CORES FOR POWER AND AC LINE FILTER

Preis auf Anfrage

Bitte erfragen Sie die Lieferzeiten

Achtung!!! Abgabe nur als Gebinde



Kern

Farbe

Außen

mm

Innen

mm

Höhe

mm

Perme-abilität



AL (nH/100Wdgg.2)

AL-Toleranz

Frequenz-bereich

Mass

(approximate)

Product Group

T44-52

grün/

Blau

11,18

5,82

4,04

µ 75

350

±10%

(>)50 kHz

1,9

gramm

PC



AL value (nominal)

35 nH/ N²

Test Winding

N=100, #34 AWG

Frequency

10 kHz

Voltage on Agilent 4284A

0.044V

Coating Type

Green/blue Epoxy Paint

Voltage Breakdown (min.)

500 Vrms, 60Hz

Limit

0.1 mA, 5 s

Density gm/cm3

7





Magnetic

Dimen-

sions

Le Eff. Mag. Path Length (cm)

Ae

Eff. Mag. Cross Section (cm2)

Veff Eff. Core Volume (cm3)

WA - Min. Eff. Window Area

sa - Surface Area

mlt - mean length per turn

2.68 cm

0.0990 cm²

0.266 cm³

0.221 cm²

4.81 cm²

1.81 cm



Core Loss

Bpk

140 G

frequency

100 kHz

Core Loss (nominal)

58 mW/cm³



Core Loss (maximum)

67 mW/cm³

where Bpk expressed in gauss, f expressed in hertz, and:

a=1.00E+09, b=1.10E+08, c=2.10E+06, d=6.90E-14



DC Saturation

HDC

50 Oe

Percent Initial Perm (nom.)

61.6%

Percent Initial Perm (min.)

53.4%

where H expressed in oersteds, and:

a=1.00E-02, b=4.66E-06, c=1.84, d=0.00



Wire

Size

AWG

18

20

22

24

26

28

30

32

34

36

38

mm

1.000

0.800

0.630

0.500

0.400

0.315

0.250

0.200

0.160

0.125

0.100

Single

Layer

Turns

11

14

18

23

29

37

47

59

74

93

116

RDC(Ω)

4.2m

8.4m

17.3m

35.1m

70.3m

142.7m

288.3 m

575.7m

1.1

2.3

4.6

Full

Winding

Turns

10

16

25

38

59

91

141

219

339

524

812

RDC(Ω)

3.8m

9.6m

24.0m

58.0m

143.1m

351.0m

865.0m

2.1

5.3

12.9

31.9

T50-0

MATERIAL 0 (Permeabilität 1)

Dieses Material wird am häufigsten für Frequenzen oberhalb 200 MHz benutzt.

Kern

Farbe

Außen

mm

Innen

mm

Höhe

mm

Perme-abilität



AL (nH/100Wdgg.2)

AL-Toleranz

Frequenz-bereich

Mass

(approximate)

Product Group

T50-0

Braun



12,70

7,70

4,83

µ 1

6,4

Ref Only

50-300 MHz

0,79

gramm

RF



AL value (nominal)

0,64 nH/ N²

Test Winding

N=100, #32 AWG

Frequency

10 kHz

Voltage on Agilent 4284A

0.040V

Coating Type

Tan/Tan Epoxy Paint

Voltage Breakdown (min.)

500 Vrms, 60Hz

Limit

0.1 mA, 5 s

Density gm/cm3

N/A





Magnetic

Dimen-

sions

Le Eff. Mag. Path Length (cm)

Ae

Eff. Mag. Cross Section (cm2)

Veff Eff. Core Volume (cm3)

WA - Min. Eff. Window Area

sa - Surface Area

mlt - mean length per turn

3.19 cm

0.112 cm²

0.358 cm³

0.406 cm²

6.44 cm²

2.03 cm



Core Loss

Bpk

140 G

frequency

100 kHz

Core Loss (nominal)

0 mW/cm³



Core Loss (maximum)

0 mW/cm³

where Bpk expressed in gauss, f expressed in hertz, and:

a=1.00E+99, b=1.00E+99, c=1.00E+99, d=0.00E+00



DC Saturation

HDC

200 Oe

Percent Initial Perm (nom.)

100%

Percent Initial Perm (min.)

100%

where H expressed in oersteds, and:

a=1.00E-02, b=0.00E+00, c=0.00, d=0.00



Wire

Size

AWG

16

18

20

22

24

26

28

30

32

34

36

mm

1.250

1.000

0.800

0.630

0.500

0.400

0.315

0.250

0.200

0.160

0.125

Single

Layer

Turns

12

15

20

25

32

41

51

64

81

101

127

RDC(Ω)

3.2m

6.4m

6.4m

26.8m

54.6 m

111.3m

220.2 m

439.4 m

884.5 m

1.8

3.5

Full

Winding

Turns

12 m

19

29

45

70

108

168

259

401

621

962

RDC(Ω)

3.2 m

8.1 m

19.6 m

48.3 m

119.5 m

293.2 m

725.3 m

1.8

4.4

10.8

26.6

t50-1

T50-1*

MATERIAL 1(11) (Permeabilität 20)

Ein "C"-gepulvertes Carbonyleisenmaterial, das dem Material '13' sehr ähnelt, aber einen höheren Volumenwiderstand und eine größere Stabilität aufweist





Kern

Farbe

Außen

mm

Innen

mm

Höhe

mm

Perme-abilität



AL (nH/100Wdgg.2)

AL-Toleranz

Frequenz-bereich

Mass

(approximate)

Product Group

T50-1

Blau

12,70

7,70

4,83

µ 20

100

±10%

0.5-5 MHz

2.3

gramm

RF

AL value (nominal)

10 nH/ N²

Test Winding

N=100, #32 AWG

Frequency

10 kHz

Voltage on Agilent 4284A

0.050V

Coating Type

Blue/Claer Epoxy Paint

Voltage Breakdown (min.)

500 Vrms, 60Hz

Limit

3 mA, 5 s

Density gm/cm3

6.4



Magnetic

Dimen-

sions

Le Eff. Mag. Path Length (cm)

Ae

Eff. Mag. Cross Section (cm2)

Veff Eff. Core Volume (cm3)

WA - Min. Eff. Window Area

sa - Surface Area

mlt - mean length per turn

3.19 cm

0.112 cm²

0.358 cm³

0.406 cm²

6.44 cm²

2,03 cm





Core Loss

Bpk

140 G

frequency

100 kHz

Core Loss (nominal)

31 mW/cm³



Core Loss (maximum)

36 mW/cm³

where Bpk expressed in gauss, f expressed in hertz, and:

a=1.90E+09, b=2.00E+08, c=9.00E+05, d=4.30E-15



DC Saturation

HDC

200 Oe

Percent Initial Perm (nom.)

82.2%

Percent Initial Perm (min.)

78%

where H expressed in oersteds, and:

a=1.00E-02, b=1.14E-06, c=1.43, d=0.00

Wire

Size

AWG

16

18

20

22

24

26

28

30

32

34

36

mm

1.250

1.000

0.800

0.630

0.500

0.400

0.315

0.250

0.200

0.160

0.125

Single

Layer

Turns

12

15

20

25

32

41

51

64

81

101

127

RDC(Ω)

3.2m

6.4m

6.4m

26.8m

54.6 m

111.3m

220.2 m

439.4 m

884.5 m

1.8

3.5

Full

Winding

Turns

12 m

19

29

45

70

108

168

259

401

621

962

RDC(Ω)

3.2 m

8.1 m

19.6 m

48.3 m

119.5 m

293.2 m

725.3 m

1.8

4.4

10.8

26.6





T50-3

MATERIAL 3 (Permeabilität 35)

Ein "HP"-gepulvertes Carbonyleisenmaterial mit ausgezeichneter Stabilität und hoher Güte für niedrige Frequenzen um 50 kHz.



Kern

Farbe

Außen

mm

Innen

mm

Höhe

mm

Perme-abilität



AL (nH/100Wdgg.2)

AL-Toleranz

Frequenz-bereich

Mass

(approximate)

Product Group

T50-3

Grau

12,70

7,70

4,83

µ 35

175

±10%

0.05-0.5 MHz

2.3

gramm

RF



AL value (nominal)

17.5 nH/ N²

Test Winding

N=100, #32 AWG

Frequency

10 kHz

Voltage on Agilent 4284A

0.050 V

Coating Type

gray Clear Epoxy Paint

Voltage Breakdown (min.)

500 Vrms, 60Hz

Limit

0.1 mA, 5 s

Density gm/cm3

6.5



Magnetic

Dimen-

sions

Le Eff. Mag. Path Length (cm)

Ae

Eff. Mag. Cross Section (cm2)

Veff Eff. Core Volume (cm3)

WA - Min. Eff. Window Area

sa - Surface Area

mlt - mean length per turn

3.19 cm

0.112 cm²

0.358 cm³

0.406 cm²

6.44 cm²

2,03 cm





Core Loss

Bpk

140 G

frequency

100 kHz

Core Loss (nominal)

31 mW/cm³



Core Loss (maximum)

36 mW/cm³

where Bpk expressed in gauss, f expressed in hertz, and:

a=1.90E+09, b=2.00E+08, c=9.00E+05, d=4.30E-15



DC Saturation

HDC

200 Oe

Percent Initial Perm (nom.)

60.1%

Percent Initial Perm (min.)

53.7%

where H expressed in oersteds, and:

a=1.00E-02, b=3.49E-06, c=1.43, d=0.00



Wire

Size

AWG

16

18

20

22

24

26

28

30

32

34

36

mm

1.250

1.000

0.800

0.630

0.500

0.400

0.315

0.250

0.200

0.160

0.125

Single

Layer

Turns

12

15

20

25

32

41

51

64

81

101

127

RDC(Ω)

3.2m

6.4m

6.4m

26.8m

54.6 m

111.3m

220.2 m

439.4 m

884.5 m

1.8

3.5

Full

Winding

Turns

12 m

19

29

45

70

108

168

259

401

621

962

RDC(Ω)

3.2 m

8.1 m

19.6 m

48.3 m

119.5 m

293.2 m

725.3 m

1.8

4.4

10.8

26.6

T50-2

MATERIAL 2 (Permeabilität 10)

Ein "E"-gepulvertes Carbonyleisenmaterial mit großem Volumenwiderstand und hoher Güte im Bereich von 1 MHz bei 30 MHz. Wird von allen Eisenpulvermaterialien am meisten verwendet.

-2 & -14 Materialien: Die geringe Permeabilität dieser Materialien führt zu einer niedrigeren AC-Flussdichte als andere Materialien ohne zusätzlichen Lückenverlust. Das -14 Material ist ähnlich -2 Material mit einer höheren Permeabilität.

-2, -4, -6 & -7 Materialien: Dies sind die beliebtesten Carbonyleisenmischungen. Sie bieten hohe Q-Werte bis zu 40 MHz und sind am beliebtesten für Amateurfunk und eine Vielzahl anderer Kommunikationsanwendungen. Sie sind auch nützlich für moderate Bandtransformatoren im Frequenzbereich von 200 bis 400 MHz



Kern

Farbe

Außen

mm

Innen

mm

Höhe

mm

Perme-abilität



AL (nH/100Wdgg.2)

AL-Toleranz

Frequenz-bereich

Mass

(approximate)

Product Group

T50-2

Rot

12,70

7,70

4,83

µ 10

49

±5%

1-30 MHz

1.8 gramm

RF

PC



AL value (nominal)

4.9 nH/ N²



Density gm/cm3

5



Test Winding

N=100, #32 AWG



Frequency

1 MHz



Voltage on Agilent 4284A

1 V



Coating Type

RED Clear Epoxy Paint



Voltage Breakdown (min.)

500 Vrms, 60Hz



Limit

0.1 mA, 5 s



Magnetic

Dimensions

Le Eff. Mag. Path Length (cm)

Ae

Eff. Mag. Cross Section (cm2)

Veff Eff. Core Volume (cm3)

WA - Min. Eff. Window Area

sa - Surface Area

mlt - mean length per turn



3.19 cm

0.112 cm²

0.358 cm³

0.406 cm²

6.44 cm²

2.03 cm



Core Loss & Q

Q Test winding

N=100,#32 AWG



Q frequenzy

1.8 MHz



Q min on HP4342A

156



where Bpk expressed in gauss, f expressed in hertz, and:

a=4.00E+09, b=3.00E+08, c=2.70E+06, d=9.60E-16



DC Saturation

HDC

Percent Initial Perm (nom.)

Percent Initial Perm (min.)

200 Oe

95.9%

94.8%



where H expressed in oersteds, and:

a=1.00E-02, b=1.78E-06, c=1.43, d=0.00



Wire Size

AWG

16

18

20

22

24

26

28

30

32

34

36

mm

1.250

1000

0.800

0.630

0.500

0.400

0.315

0.250

0.200

0.160

0.125

Single Layer

Turns

12

15

20

25

32

41

51

64

81

101

127

RDC(Ω)

3.2 m

6.4 m

6.4 m

26.8 m

54,6 m

111.3 m

220.2 m

439.4 m

884.5 m

1.8

3.5

Full Winding

Turns

12 m

19

29

45

70

108

168

259

401

621

962

RDC(Ω)

3.2 m

8.1 m

19.6 m

48.3 m

119.5 m

293.2 m

725.2 m

1.8

4.4

10.8

29.6

T50-6*

MATERIAL 6 (Permeabilität 8)

Ein "SF"-gepulvertes Eisenmaterial, das dem Material "2" sehr ähnelt, aber verbesserte Güte für höhere Frequenzen bis 50 MHz aufweist.

Kern

Farbe

Außen

mm

Innen

mm

Höhe

mm

Perme-abilität



AL (nH/100Wdgg.2)

AL-Toleranz

Frequenz-bereich

Mass

(approximate)

Product Group

T50-6

Gelb

12,70

7,70

4,83

µ 8

40

±5%

2-50 MHz

1.8 gramm

RF



AL value (nominal)

4.0 nH/ N²



Density gm/cm3

5



Test Winding

N=50, #27 AWG



Frequency

1 MHz



Voltage on Agilent 4284A

1 V



Coating Type

Yellow Clear Epoxy Paint



Voltage Breakdown (min.)

500 Vrms, 60Hz



Limit

0.1 mA, 5 s



Magnetic

Dimensions

Le Eff. Mag. Path Length (cm)

Ae

Eff. Mag. Cross Section (cm2)

Veff Eff. Core Volume (cm3)

WA - Min. Eff. Window Area

sa - Surface Area

mlt - mean length per turn



3.19 cm

0.112 cm²

0.358 cm³

0.406 cm²

6.44 cm²

2.03 cm



Core Loss & Q

Q Test winding

N=25,#22 AWG



Q frequenzy

10 MHz



Q min on HP4342A

237



where Bpk expressed in gauss, f expressed in hertz, and:

a=4.00E+09, b=3.00E+08, c=2.70E+06, d=9.60E-16



DC Saturation

HDC

Percent Initial Perm (nom.)

Percent Initial Perm (min.)

200 Oe

98.1%

97.4%



where H expressed in oersteds, and:

a=1.00E-02, b=4.87E-08, c=1.57, d=0.00



Wire Size

AWG

16

18

20

22

24

26

28

30

32

34

36

mm

1.250

1000

0.800

0.630

0.500

0.400

0.315

0.250

0.200

0.160

0.125

Single Layer

Turns

12

15

20

25

32

41

51

64

81

101

127

RDC(Ω)

3.2 m

6.4 m

6.4 m

26.8 m

54,6 m

111.3 m

220.2 m

439.4 m

884.5 m

1.8

3.5

Full Winding

Turns

12 m

19

29

45

70

108

168

259

401

621

962

RDC(Ω)

3.2 m

8.1 m

19.6 m

48.3 m

119.5 m

293.2 m

725.2 m

1.8

4.4

10.8

29.6

T50-10

MATERIAL 10 (Permeabilität 6)

Ein "W"-gepulvertes Carbonyleisenmaterial, das hohe Güte und Stabilität für Frequenzen bis 100 MHz aufweist.

Kern

Farbe

Außen

mm

Innen

mm

Höhe

mm

Perme-abilität



AL (nH/100Wdgg.2)

AL-Toleranz

Frequenz-bereich

Mass

(approximate)

Product Group

T50-10

Schwarz

12,70

7,70

4,83

µ 6

31

±5%

10-100 MHz

1,8

gramm

RF



AL value (nominal)

3.1 nH/ N²

Test Winding

N=25, #24 AWG

Frequency

1 MHz

Voltage on Agilent 4284A

1 V

Coating Type

Black Clear Epoxy Paint

Voltage Breakdown (min.)

500 Vrms, 60Hz

Limit

0.1 mA, 5 s

Density gm/cm3

5



Magnetic

Dimen-

sions

Le Eff. Mag. Path Length (cm)

Ae

Eff. Mag. Cross Section (cm2)

Veff Eff. Core Volume (cm3)

WA - Min. Eff. Window Area

sa - Surface Area

mlt - mean length per turn

3.19 cm

0.112 cm²

0.358 cm³

0.406 cm²

6.44 cm²

2,03 cm





Core Loss & Q

Q Test winding

N=35, #24 AWG

Q frequency

9 MHz

Q min on HP4342A

158

where Bpk expressed in gauss, f expressed in hertz, and:

a=4.00E+09, b=3.00E+08, c=2.70E+06, d=8.00E-16



DC Saturation

HDC

200 Oe

Percent Initial Perm (nom.)

99.6%

Percent Initial Perm (min.)

99.4%

where H expressed in oersteds, and:

a=1.00E-02, b=5.54E-09, c=1.69, d=0.00



Wire

Size

AWG

16

18

20

22

24

26

28

30

32

34

36

mm

1.250

1.000

0.800

0.630

0.500

0.400

0.315

0.250

0.200

0.160

0.125

Single

Layer

Turns

12

15

20

25

32

41

51

64

81

101

127

RDC(Ω)

3.2m

6.4m

6.4m

26.8m

54.6 m

111.3m

220.2 m

439.4 m

884.5 m

1.8

3.5

Full

Winding

Turns

12 m

19

29

45

70

108

168

259

401

621

962

RDC(Ω)

3.2 m

8.1 m

19.6 m

48.3 m

119.5 m

293.2 m

725.3 m

1.8

4.4

10.8

26.6

T50-11



MATERIAL 11( (Permeabilität 20)

Ein "C"-gepulvertes Carbonyleisenmaterial, das dem Material '13' sehr ähnelt, aber einen höheren Volumenwiderstand und eine größere Stabilität aufweist



Kern

Farbe

Außen

mm

Innen

mm

Höhe

mm

Perme-abilität



AL (nH/100Wdgg.2)

AL-Toleranz

Frequenz-bereich

Mass

(approximate)

Product Group

T50-11

Blau

12,70

7,70

4,83

µ 20

100

±10%

0.5-5 MHz

2.3

gramm

RF



AL value (nominal)

10 nH/ N²

Test Winding

N=100, #32 AWG

Frequency

10 kHz

Voltage on Agilent 4284A

0.050V

Coating Type

Blue/Claer Epoxy Paint

Voltage Breakdown (min.)

500 Vrms, 60Hz

Limit

3 mA, 5 s

Density gm/cm3

6.4



Magnetic

Dimen-

sions

Le Eff. Mag. Path Length (cm)

Ae

Eff. Mag. Cross Section (cm2)

Veff Eff. Core Volume (cm3)

WA - Min. Eff. Window Area

sa - Surface Area

mlt - mean length per turn

3.19 cm

0.112 cm²

0.358 cm³

0.406 cm²

6.44 cm²

2.03 cm



Core Loss

Bpk

140 G

frequency

100 kHz

Core Loss (nominal)

31 mW/cm³



Core Loss (maximum)

36 mW/cm³

where Bpk expressed in gauss, f expressed in hertz, and:

a=1.90E+09, b=2.00E+08, c=9.00E+05, d=4.30E-15



DC Saturation

HDC

200 Oe

Percent Initial Perm (nom.)

82.2%

Percent Initial Perm (min.)

78%

where H expressed in oersteds, and:

a=1.00E-02, b=1.14E-06, c=1.43, d=0.00



Wire

Size

AWG

16

18

20

22

24

26

28

30

32

34

36

mm

1.250

1.000

0.800

0.630

0.500

0.400

0.315

0.250

0.200

0.160

0.125

Single

Layer

Turns

12

15

20

25

32

41

51

64

81

101

127

RDC(Ω)

3.2m

6.4m

6.4m

26.8m

54.6 m

111.3m

220.2 m

439.4 m

884.5 m

1.8

3.5

Full

Winding

Turns

12 m

19

29

45

70

108

168

259

401

621

962

RDC(Ω)

3.2 m

8.1 m

19.6 m

48.3 m

119.5 m

293.2 m

725.3 m

1.8

4.4

10.8

26.6

T50-12

T50-12 - MATERIAL 12 (Permeabilität 4 )

Ein synthetisches Oxidmaterial, das eine mittlere Güte und Stabilität oberhalb von 100 MHz besitzt.



Kern

Farbe

Außen

mm

Innen

mm

Höhe

mm

Perme-abilität



AL (nH/100Wdgg.2)

AL-Toleranz

Frequenz-bereich

Mass

(approximate)

Product Group

T50-12

Grün/

weiß

12,70

7,70

4,83

µ 4

18

±5%

20-200 MHz

#N/A

RF



AL value (nominal)

17.5 nH/ N²

Test Winding

N=100, #32 AWG

Frequency

10 kHz

Voltage on Agilent 4284A

0.050 V

Coating Type

grey/white Epoxy Paint

Voltage Breakdown (min.)

500 Vrms, 60Hz

Limit

0.1 mA, 5 s

Density gm/cm3

6.5



Magnetic

Dimen-

sions

Le Eff. Mag. Path Length (cm)

Ae

Eff. Mag. Cross Section (cm2)

Veff Eff. Core Volume (cm3)

WA - Min. Eff. Window Area

sa - Surface Area

mlt - mean length per turn

3.19 cm

0.112 cm²

0.358 cm³

0.406 cm²

6.44 cm²

2,03 cm





Core Loss

Bpk

#N/A

frequency

#N/A

Core Loss (nominal)

#N/A



Core Loss (maximum)

#N/A

where Bpk expressed in gauss, f expressed in hertz, and:

#N/A



DC Saturation

HDC

#N/A

Percent Initial Perm (nom.)

#N/A

Percent Initial Perm (min.)

#N/A

where H expressed in oersteds, and:

#N/A



Wire

Size

AWG

16

18

20

22

24

26

28

30

32

34

36

mm

1.250

1.000

0.800

0.630

0.500

0.400

0.315

0.250

0.200

0.160

0.125

Single

Layer

Turns

12

15

20

25

32

41

51

64

81

101

127

RDC(Ω)

3.2m

6.4m

6.4m

26.8m

54.6 m

111.3m

220.2 m

439.4 m

884.5 m

1.8

3.5

Full

Winding

Turns

12 m

19

29

45

70

108

168

259

401

621

962

RDC(Ω)

3.2 m

8.1 m

19.6 m

48.3 m

119.5 m

293.2 m

725.3 m

1.8

4.4

10.8

26.6

T50-13

MATERIAL 13 (Permeabilität 35)

Ein "HP"-gepulvertes Carbonyleisenmaterial mit ausgezeichneter Stabilität und hoher Güte für niedrige Frequenzen um 50 kHz

Kern

Farbe

Außen

mm

Innen

mm

Höhe

mm

Perme-abilität



AL (nH/100Wdgg.2)

AL-Toleranz

Frequenz-bereich

Mass

(approximate)

Product Group

T50-13

Grau

12,70

7,70

4,83

µ 35

175

±10%

0.05-0.5 MHz

2.3

gramm

RF



AL value (nominal)

17.5 nH/ N²

Test Winding

N=100, #32 AWG

Frequency

10 kHz

Voltage on Agilent 4284A

0.050 V

Coating Type

gray Epoxy Paint

Voltage Breakdown (min.)

500 Vrms, 60Hz

Limit

0.1 mA, 5 s

Density gm/cm3

6.5



Magnetic

Dimen-

sions

Le Eff. Mag. Path Length (cm)

Ae

Eff. Mag. Cross Section (cm2)

Veff Eff. Core Volume (cm3)

WA - Min. Eff. Window Area

sa - Surface Area

mlt - mean length per turn

3.19 cm

0.112 cm²

0.358 cm³

0.406 cm²

6.44 cm²

2,03 cm







Core Loss

Bpk

140 G

frequency

100 kHz

Core Loss (nominal)

31 mW/cm³



Core Loss (maximum)

36 mW/cm³

where Bpk expressed in gauss, f expressed in hertz, and:

a=1.90E+09, b=2.00E+08, c=9.00E+05, d=4.30E-15



DC Saturation

HDC

200 Oe

Percent Initial Perm (nom.)

60.1%

Percent Initial Perm (min.)

53.7%

where H expressed in oersteds, and:

a=1.00E-02, b=3.49E-06, c=1.43, d=0.00

Wire

Size

AWG

16

18

20

22

24

26

28

30

32

34

36

mm

1.250

1.000

0.800

0.630

0.500

0.400

0.315

0.250

0.200

0.160

0.125

Single

Layer

Turns

12

15

20

25

32

41

51

64

81

101

127

RDC(Ω)

3.2m

6.4m

6.4m

26.8m

54.6 m

111.3m

220.2 m

439.4 m

884.5 m

1.8

3.5

Full

Winding

Turns

12 m

19

29

45

70

108

168

259

401

621

962

RDC(Ω)

3.2 m

8.1 m

19.6 m

48.3 m

119.5 m

293.2 m

725.3 m

1.8

4.4

10.8

26.6



T50-15

MATERIAL 15 (Permeabilität 25)

Ein "GS-6"-gepulvertes Eisenmaterial (Carbonyl), das gute Stabilität für kommerzielle Rundfunkfrequenzen bietet, wo hohe Güte und eine gleichmäßige Permeabilität erforderlich sind.

Kern

Farbe

Außen

mm

Innen

mm

Höhe

mm

Perme-abilität



AL (nH/100Wdgg.2)

AL-Toleranz

Frequenz-bereich

Mass

(approximate)

Product Group

T50-15

Weiß/Rot

12,70

7,70

4,83

µ 25

135

±10%

0.1-2 MHz

2,3 gramm

RF



AL value (nominal)

13.5 nH/ N²

Density gm/cm3

6.4

Test Winding

N=100, #32 AWG

Frequency

10 kHz

Voltage on Agilent 4284A

0.050 V

Coating Type

White/red Epoxy Paint

Voltage Breakdown (min.)

500 Vrms, 60Hz

Limit

0.1 mA, 5 s

Magnetic

Dimensions

Le Eff. Mag. Path Length (cm)

Ae

Eff. Mag. Cross Section (cm2)

Veff Eff. Core Volume (cm3)

WA - Min. Eff. Window Area

sa - Surface Area

mlt - mean length per turn

3.19 cm

0.112 cm²

0.358 cm³

0.406 cm²

6.44 cm²

2.03 cm

Core Loss

Bpk

140 G

frequenzy

100 kHz

Core Loss (nominal)

32 mW/cm³

Core Loss (maximum)

36 mW/cm³

where Bpk expressed in gauss, f expressed in hertz, and:

a=1.90E+09, b=2.00E+08, c=9.00E+05, d=5.00E-15



DC Saturation





HDC

Percent Initial Perm (nom.)

Percent Initial Perm (min.)

200 Oe

74.7%

69.4%

where H expressed in oersteds, and:

a=1.00E-02, b=1.78E-06, c=1.43, d=0.00

Wire Size

AWG

16

18

20

22

24

26

28

30

32

34

36

mm

1.250

1.000

0.800

0.630

0.500

0.400

0.315

0.250

0.200

0.160

0.125

Single

Layer

Turns

12

15

20

25

32

41

51

64

81

101

127

RDC(Ω)

3.2m

6.4m

6.4m

26.8m

54.6 m

111.3m

220.2 m

439.4 m

884.5 m

1.8

3.5

Full

Winding

Turns

12 m

19

29

45

70

108

168

259

401

621

962

RDC(Ω)

3.2 m

8.1 m

19.6 m

48.3 m

119.5 m

293.2 m

725.3 m

1.8

4.4

10.8

26.6

T50-17*

MATERIAL 17 - Permeabilität 4

Ein synthetisches Oxidmaterial, das eine mittlere Güte und Stabilität oberhalb von 100 MHz besitzt..

Material 17 Ähnelt sehr dem Material 12, hat aber einen stark verringerten Temperaturgang. Die Güte, die bei Benutzung dieses Materials erreicht werden kann, liegt um etwa 10% unter der von Material "12". Dies sollte aber hingenommen werden, wenn geringere Temperaturgang von vorrangiger Bedeutung ist.



Kern

Farbe

Außen

mm

Innen

mm

Höhe

mm

Perme-abilität



AL (nH/100Wdgg.2)

AL-Toleranz

Frequenz-bereich

Mass

(approximate)

Product Group

T50-17

Blau/Gelb

12,70

7,70

4,83

µ 4

18

±5%

20-200 MHz

1.7 gramm

RF



AL value (nominal)

1.8 nH/ N²



Density gm/cm3

6.8



Test Winding

N=100, #32 AWG



Frequency

1 MHz



Voltage on Agilent 4284A

1 V



Coating Type

Blue/Yellow Epoxy Paint



Voltage Breakdown (min.)

500 Vrms, 60Hz



Limit

0.1 mA, 5 s



Magnetic

Dimensions

Le Eff. Mag. Path Length (cm)

Ae

Eff. Mag. Cross Section (cm2)

Veff Eff. Core Volume (cm3)

WA - Min. Eff. Window Area

sa - Surface Area

mlt - mean length per turn



3.19 cm

0.112 cm²

0.358 cm³

0.406 cm²

6.44 cm²

2.03 cm



Core Loss & Q

Q Test Winding

N=15, #20 AWG



Q frequenzy

25 MHz



Q min on HP4342A

159



where Bpk expressed in gauss, f expressed in hertz, and:

a=4.00E+09, b=3.00E+08, c=2.70E+06, d=4.40E-16



DC Saturation

HDC

Percent Initial Perm (nom.)

Percent Initial Perm (min.)

200 Oe

99.5%

99.4%



where H expressed in oersteds, and:

a=1.00E-02, b=1.34E-08, c=1.55, d=0.00



Wire Size

AWG

16

18

20

22

24

26

28

30

32

34

36

mm

1.250

1000

0.800

0.630

0.500

0.400

0.315

0.250

0.200

0.160

0.125

Single Layer

Turns

12

15

20

25

32

41

51

64

81

101

127

RDC(Ω)

3.2 m

6.4 m

6.4 m

26.8 m

54,6 m

111.3 m

220.2 m

439.4 m

884.5 m

1.8

3.5

Full Winding

Turns

12 m

19

29

45

70

108

168

259

401

621

962

RDC(Ω)

3.2 m

8.1 m

19.6 m

48.3 m

119.5 m

293.2 m

725.2 m

1.8

4.4

10.8

29.6

t106-18b

T50-18

MATERIAL 18 (Permeabilität 55)

Dieses Material hat einen geringen Kernverlust wie das Material -8 mit höherer Permeabilität. Gute DC-Sättigungseigenschaften.

Für Leistungsanwendung 50/60Hz - bis 500 kHz



Preis-und Lieferzeit auf Anfrage

Kern

Farbe

Außen

mm

Innen

mm

Höhe

mm

Perme-abilität



AL (nH/100Wdgg.2)

AL-Toleranz

Frequenz-bereich

Mass

(approximate)

Product Group

T50-18

Grün/Rot

12,70

7,70

4,83

µ 55

24

±10%

DC-Drossel

Leistungsdrossel

2.4 gramm

PC



AL value (nominal)

2.4 nH/ N²



Density gm/cm3

6.6



Test Winding

N=100, #32 AWG



Frequency

10 kHz



Voltage on Agilent 4284A

0.050 V



Coating Type

Green/Red Epoxy Paint



Voltage Breakdown (min.)

500 Vrms, 60Hz



Limit

0.1 mA, 5 s



Magnetic

Dimensions

Le Eff. Mag. Path Length (cm)

Ae

Eff. Mag. Cross Section (cm2)

Veff Eff. Core Volume (cm3)

WA - Min. Eff. Window Area

sa - Surface Area

mlt - mean length per turn



3.19 cm

0.112 cm²

0.358 cm³

0.406 cm²

6.44 cm²

2.03 cm





Core Loss

Bpk

140 G



frequenzy

100 kHz



Core Loss (nominal)

46 mW/cm³



Core Loss (maximum)

53 mW/cm³



where Bpk expressed in gauss, f expressed in hertz, and:

a=8.00E+08, b=1.70E+08, c=9.00E+05, d=3.10E-14



DC Saturation

HDC

Percent Initial Perm (nom.)

Percent Initial Perm (min.)

200 Oe

51.4%

43.9%



where H expressed in oersteds, and:

a=1.00E-02, b=4.72E-06, c=1.65, d=0.00



Wire Size

AWG

16

18

20

22

24

26

28

30

32

34

36

mm

1.250

1000

0.800

0.630

0.500

0.400

0.315

0.250

0.200

0.160

0.125

Single Layer

Turns

12

15

20

25

32

41

51

64

81

101

127

RDC(Ω)

3.2 m

6.4 m

6.4 m

26.8 m

54,6 m

111.3 m

220.2 m

439.4 m

884.5 m

1.8

3.5

Full Winding

Turns

12 m

19

29

45

70

108

168

259

401

621

962

RDC(Ω)

3.2 m

8.1 m

19.6 m

48.3 m

119.5 m

293.2 m

725.2 m

1.8

4.4

10.8

29.6

T50-25

MATERIAL 25 (Permeabilität 25)

Ein "GS-6"-gepulvertes Eisenmaterial (Carbonyl), das gute Stabilität für kommerzielle Rundfunkfrequenzen bietet, wo hohe Güte und eine gleichmäßige Permeabilität erforderlich sind.

Kern

Farbe

Außen

mm

Innen

mm

Höhe

mm

Perme-abilität



AL (nH/100Wdgg.2)

AL-Toleranz

Frequenz-bereich

Mass

(approximate)

Product Group

T50-25

Weiß/Rot

12,70

7,70

4,83

µ 25

135

±10%

0.1-2 MHz

2,3 gramm

RF



AL value (nominal)

13.5 nH/ N²

Density gm/cm3

6.4

Test Winding

N=100, #32 AWG

Frequency

10 kHz

Voltage on Agilent 4284A

0.050 V

Coating Type

White/red Epoxy Paint

Voltage Breakdown (min.)

500 Vrms, 60Hz

Limit

0.1 mA, 5 s

Magnetic

Dimensions

Le Eff. Mag. Path Length (cm)

Ae

Eff. Mag. Cross Section (cm2)

Veff Eff. Core Volume (cm3)

WA - Min. Eff. Window Area

sa - Surface Area

mlt - mean length per turn

3.19 cm

0.112 cm²

0.358 cm³

0.406 cm²

6.44 cm²

2.03 cm

Core Loss

Bpk

140 G

frequenzy

100 kHz

Core Loss (nominal)

32 mW/cm³

Core Loss (maximum)

36 mW/cm³

where Bpk expressed in gauss, f expressed in hertz, and:

a=1.90E+09, b=2.00E+08, c=9.00E+05, d=5.00E-15



DC Saturation





HDC

Percent Initial Perm (nom.)

Percent Initial Perm (min.)

200 Oe

74.7%

69.4%

where H expressed in oersteds, and:

a=1.00E-02, b=1.78E-06, c=1.43, d=0.00

Wire Size

AWG

16

18

20

22

24

26

28

30

32

34

36

mm

1.250

1.000

0.800

0.630

0.500

0.400

0.315

0.250

0.200

0.160

0.125

Single

Layer

Turns

12

15

20

25

32

41

51

64

81

101

127

RDC(Ω)

3.2m

6.4m

6.4m

26.8m

54.6 m

111.3m

220.2 m

439.4 m

884.5 m

1.8

3.5

Full

Winding

Turns

12 m

19

29

45

70

108

168

259

401

621

962

RDC(Ω)

3.2 m

8.1 m

19.6 m

48.3 m

119.5 m

293.2 m

725.3 m

1.8

4.4

10.8

26.6

T50-26

MATERIAL 26 (Permeabilität 70)

-26- & 36 Material: Ein sehr populäres Material, es ist ein kostengünstiges Allzweckmaterial, das in einer Vielzahl von Stromumwandlungs- und Netzfilteranwendungen nützlich ist.

Ein wasserstoffreduziertes Eisenmaterial, das Material '41' sehr ähnelt, aber einen erweiterten Frequenzbereich bietet.

50/60Hz - bis 500 kHz für Leistungsan

Bevorzugte Anwendungsbereiche:
Licht-Dimmer-Drosseln 50/60 Hz,

EMI-Netz Drosseln

DC-Drosseln <50 kHz

Leistungsfaktor-Korrektur Drosseln <50 kHz.

Kern

Farbe

Außen

mm

Innen

mm

Höhe

mm

Perme-abilität



AL (nH/100Wdgg.2)

AL-Toleranz

Frequenz-bereich

Mass

(approximate)

Product Group

T50-26

Gelb/Weiß

12,70

7,70

4,83

µ 70

33

±10%

DC-1 MHz

2.5

gramm

PC



AL value (nominal)

7.0 nH/ N²



Density gm/cm3

7.0



Test Winding

N=100, #32 AWG



Frequency

10 kHz



Voltage on Agilent 4284A

0.050 V



Coating Type

Yellow/White Epoxy Paint



Voltage Breakdown (min.)

500 Vrms, 60Hz



Limit

0.1 mA, 5 s



Magnetic

Dimensions

Le Eff. Mag. Path Length (cm)

Ae

Eff. Mag. Cross Section (cm2)

Veff Eff. Core Volume (cm3)

WA - Min. Eff. Window Area

sa - Surface Area

mlt - mean length per turn



3.19 cm

0.112 cm²

0.358 cm³

0.406 cm²

6.44 cm²

2.03 cm





Core Loss

Bpk

140 G



frequenzy

100 kHz



Core Loss (nominal)

83 mW/cm³



Core Loss (maximum)

95 mW/cm³



where Bpk expressed in gauss, f expressed in hertz, and:

a=1.00E+09, b=1.10E+08, c=1.90E+06, d=1.90E-13



DC Saturation

HDC

Percent Initial Perm (nom.)

Percent Initial Perm (min.)

50 Oe

55.2%

47.4%



where H expressed in oersteds, and:

a=1.00E-02, b=9.70E-06, c=1.72, d=0.00



Wire Size

AWG

16

18

20

22

24

26

28

30

32

34

36

mm

1.250

1000

0.800

0.630

0.500

0.400

0.315

0.250

0.200

0.160

0.125

Single Layer

Turns

12

15

20

25

32

41

51

64

81

101

127

RDC(Ω)

3.2 m

6.4 m

6.4 m

26.8 m

54,6 m

111.3 m

220.2 m

439.4 m

884.5 m

1.8

3.5

Full Winding

Turns

12 m

19

29

45

70

108

168

259

401

621

962

RDC(Ω)

3.2 m

8.1 m

19.6 m

48.3 m

119.5 m

293.2 m

725.2 m

1.8

4.4

10.8

29.6

T50-36

MATERIAL 36 (Permeabilität 75)

-26- & 36 Material: Ein sehr populäres Material, es ist ein kostengünstiges Allzweckmaterial, das in einer Vielzahl von Stromumwandlungs- und Netzfilteranwendungen nützlich ist.

Ein wasserstoffreduziertes Eisenmaterial, das Material '41' sehr ähnelt, aber einen erweiterten Frequenzbereich bietet.

50/60Hz - bis 500 kHz für Leistungsan

Bevorzugte Anwendungsbereiche:
Licht-Dimmer-Drosseln 50/60 Hz,

EMI-Netz Drosseln

DC-Drosseln <50 kHz

Leistungsfaktor-Korrektur Drosseln <50 kHz.

Kern

Farbe

Außen

mm

Innen

mm

Höhe

mm

Perme-abilität



AL (nH/100Wdgg.2)

AL-Toleranz

Frequenz-bereich

Mass

(approximate)

Product Group

T50-36

Weiß/Gelb

12,70

7,70

4,83

µ 75

33

±10%

DC-1 MHz

2.5

gramm

PC



AL value (nominal)

7.5 nH/ N²



Density gm/cm3

7.0



Test Winding

N=100, #32 AWG



Frequency

10 kHz



Voltage on Agilent 4284A

0.050 V



Coating Type

White/Yellow Epoxy Paint



Voltage Breakdown (min.)

500 Vrms, 60Hz



Limit

0.1 mA, 5 s



Magnetic

Dimensions

Le Eff. Mag. Path Length (cm)

Ae

Eff. Mag. Cross Section (cm2)

Veff Eff. Core Volume (cm3)

WA - Min. Eff. Window Area

sa - Surface Area

mlt - mean length per turn



3.19 cm

0.112 cm²

0.358 cm³

0.406 cm²

6.44 cm²

2.03 cm





Core Loss

Bpk

140 G



frequenzy

100 kHz



Core Loss (nominal)

83 mW/cm³



Core Loss (maximum)

95 mW/cm³



where Bpk expressed in gauss, f expressed in hertz, and:

a=1.00E+09, b=1.10E+08, c=1.90E+06, d=1.90E-13



DC Saturation

HDC

Percent Initial Perm (nom.)

Percent Initial Perm (min.)

50 Oe

55.2%

47.4%



where H expressed in oersteds, and:

a=1.00E-02, b=9.70E-06, c=1.72, d=0.00



Wire Size

AWG

16

18

20

22

24

26

28

30

32

34

36

mm

1.250

1000

0.800

0.630

0.500

0.400

0.315

0.250

0.200

0.160

0.125

Single Layer

Turns

12

15

20

25

32

41

51

64

81

101

127

RDC(Ω)

3.2 m

6.4 m

6.4 m

26.8 m

54,6 m

111.3 m

220.2 m

439.4 m

884.5 m

1.8

3.5

Full Winding

Turns

12 m

19

29

45

70

108

168

259

401

621

962

RDC(Ω)

3.2 m

8.1 m

19.6 m

48.3 m

119.5 m

293.2 m

725.2 m

1.8

4.4

10.8

29.6

T50-52

-52 Material: Dieses Material hat geringere Kernverluste bei hoher Frequenz und die gleiche Durchlässigkeit wie das -26 und -36  Material. Es ist beliebt für Hochfrequenz-Choke-Designs und in einer Vielzahl von Geometrien verfügbar.

‐52 Material: This material has lower core losses at high frequency and the same permeability as the ‐26 and -36 Material. It is popular for high frequency choke designs and available in a wide variety of geometries.

Preis auf Anfrage

Bitte erfragen Sie die Lieferzeiten

Achtung!!! Abgabe nur als Gebinde



Material 52 (Permeabilität 75)

50/60 Hz- Differential mode EMI Line-Chokes

z.B.350 µ H -100 Umdrehungen=35,0nH/N²

IRON POWDER TOROIDAL CORES FOR POWER AND AC LINE FILTER

Kern

Farbe

Außen

mm

Innen

mm

Höhe

mm

Perme-abilität



AL (nH/100Wdgg.2)

AL-Toleranz

Frequenz-bereich

Mass

(approximate)

Product Group

T50-52

Grün/

Blau

12,70

7,70

4,83

µ 75

330

±10%

(>)50 kHz

2.5

gramm

PC



AL value (nominal)

33 nH/ N²



Density gm/cm3

7.0



Test Winding

N=100, #32 AWG



Frequency

10 kHz



Voltage on Agilent 4284A

0.050 V



Coating Type

Green/Blue Epoxy Paint



Voltage Breakdown (min.)

500 Vrms, 60Hz



Limit

0.1 mA, 5 s



Magnetic

Dimensions

Le Eff. Mag. Path Length (cm)

Ae

Eff. Mag. Cross Section (cm2)

Veff Eff. Core Volume (cm3)

WA - Min. Eff. Window Area

sa - Surface Area

mlt - mean length per turn



3.19 cm

0.112 cm²

0.358 cm³

0.406 cm²

6.44 cm²

2.03 cm





Core Loss

Bpk

140 G



frequenzy

100 kHz



Core Loss (nominal)

58mW/cm³



Core Loss (maximum)

67mW/cm³



where Bpk expressed in gauss, f expressed in hertz, and:

a=1.00E+09, b=1.10E+08, c=2.10E+06, d=6.90E-14



DC Saturation

HDC

Percent Initial Perm (nom.)

Percent Initial Perm (min.)

50 Oe

61.6%

53.4%



where H expressed in oersteds, and:

a=1.00E-02, b=4.66E-06, c=1.84, d=0.00



Wire Size

AWG

16

18

20

22

24

26

28

30

32

34

36

mm

1.250

1000

0.800

0.630

0.500

0.400

0.315

0.250

0.200

0.160

0.125

Single Layer

Turns

12

15

20

25

32

41

51

64

81

101

127

RDC(Ω)

3.2 m

6.4 m

6.4 m

26.8 m

54,6 m

111.3 m

220.2 m

439.4 m

884.5 m

1.8

3.5

Full Winding

Turns

12 m

19

29

45

70

108

168

259

401

621

962

RDC(Ω)

3.2 m

8.1 m

19.6 m

48.3 m

119.5 m

293.2 m

725.2 m

1.8

4.4

10.8

29.6

T68-0

MATERIAL 0 (Permeabilität 1)

Dieses Material wird am häufigsten für Frequenzen oberhalb 200 MHz benutzt.

Kern

Farbe

Außen

mm

Innen

mm

Höhe

mm

Perme-abilität



AL (nH/100Wdgg.2)

AL-Toleranz

Frequenz-bereich

Mass

(approximate)

Product Group

T68-0

Braun

17.53

9.40

4,83

µ 1

7.5

Ref Only

50-300 MHz

1.7

gramm

RF



AL value (nominal)

0.75 nH/ N²

Density gm/cm3

7.0

Test Winding

N=100, #30 AWG

Frequency

10 kHz

Voltage on Agilent 4284A

0.047 V

Coating Type

Tan/Tan Epoxy Paint

Voltage Breakdown (min.)

500 Vrms, 60Hz

Limit

0.1 mA, 5 s

Magnetic

Dimensions

Le Eff. Mag. Path Length (cm)

Ae

Eff. Mag. Cross Section (cm2)

Veff Eff. Core Volume (cm3)

WA - Min. Eff. Window Area

sa - Surface Area

mlt - mean length per turn

4.23 cm

0.179 cm²

0.358 cm³

0.759 cm²

10.6 cm²

2.43 cm



Core Loss

Bpk

140 G

frequenzy

100 kHz

Core Loss (nominal)

0 mW/cm³

Core Loss (maximum)

0 mW/cm³

where Bpk expressed in gauss, f expressed in hertz, and:

a=1.00E+99, b=1.00E+99, c=1.00E+99, d=0.00E+00

DC Saturation

HDC

Percent Initial Perm (nom.)

Percent Initial Perm (min.)

200 Oe

100.0%

100.0%

where H expressed in oersteds, and:

a=1.00E-02, b=0.00E+00, c=0.00, d=0.00

Wire Size

AWG

14

16

18

20

22

24

26

28

30

32

34

mm

1.600

1.250

1000

0.800

0.630

0.500

0.400

0.315

0.250

0.200

0.160

Single Layer

Turns

12

15

20

25

32

40

51

64

80

101

126

RDC(Ω)

2.4 m

4.8 m

10.1 m

20.2 m

41.1 m

81.7 m

165.6 m

330.4 m

656.9 m

1.3

2.6

Full Winding

Turns

12

19 m

29

45

69

107

166

256

397

614

950

RDC(Ω)

2.4 m

6.1 m

14.7 m

36.3 m

88.6 m

218.4 m

538.9 m

1.3

3.3

8.0

19.7



t68-1

T68-1

MATERIAL 1 (Permeabilität 20)

Ein "C"-gepulvertes Carbonyleisenmaterial, das dem Material '13' sehr ähnelt, aber einen höheren Volumenwiderstand und eine größere Stabilität aufweist.

Kern

Farbe

Außen

mm

Innen

mm

Höhe

mm

Perme-abilität



AL (nH/100Wdgg.2)

AL-Toleranz

Frequenz-bereich

Mass

(approximate)

Product Group

T68-1

Blau

17.53

9.40

4,83

µ 20

115

10%

0.05-5 MHz

4.9

gramm

RF





AL value (nominal)

11.5 nH/ N²

Density gm/cm3

6.4

Test Winding

N=100, #30 AWG

Frequency

10 kHz

Voltage on Agilent 4284A

0.079 V

Coating Type

Blue/Clear Epoxy Paint

Voltage Breakdown (min.)

500 Vrms, 60Hz

Limit

0.1 mA, 5 s

Magnetic

Dimensions

Le Eff. Mag. Path Length (cm)

Ae

Eff. Mag. Cross Section (cm2)

Veff Eff. Core Volume (cm3)

WA - Min. Eff. Window Area

sa - Surface Area

mlt - mean length per turn

4.23 cm

0.179 cm²

0.358 cm³

0.759 cm²

10.6 cm²

2.43 cm



Core Loss

Bpk

140 G

frequenzy

100 kHz

Core Loss (nominal)

31mW/cm³

Core Loss (maximum)

36 mW/cm³

where Bpk expressed in gauss, f expressed in hertz, and:

a=1.90E+09, b=2.00E+08, c=9.00E+05, d=4.30E-15

DC Saturation

HDC

Percent Initial Perm (nom.)

Percent Initial Perm (min.)

200 Oe

82.2%

78.0%

where H expressed in oersteds, and:

a=1.00E-02, b=1.14E-06, c=1.43, d=0.00

Wire Size

AWG

14

16

18

20

22

24

26

28

30

32

34

mm

1.600

1.250

1000

0.800

0.630

0.500

0.400

0.315

0.250

0.200

0.160

Single Layer

Turns

12

15

20

25

32

40

51

64

80

101

126

RDC(Ω)

2.4 m

4.8 m

10.1 m

20.2 m

41.1 m

81.7 m

165.6 m

330.4 m

656.9 m

1.3

2.6

Full Winding

Turns

12

19 m

29

45

69

107

166

256

397

614

950

RDC(Ω)

2.4 m

6.1 m

14.7 m

36.3 m

88.6 m

218.4 m

538.9 m

1.3

3.3

8.0

19.7



T68-2

MATERIAL 2 (Permeabilität 10)

Ein "E"-gepulvertes Carbonyleisenmaterial mit großem Volumenwiderstand und hoher Güte im Bereich von 1 MHz bei 30 MHz. Wird von allen Eisenpulvermaterialien am meisten verwendet.

-2 & -14 Materialien: Die geringe Permeabilität dieser Materialien führt zu einer niedrigeren AC-Flussdichte als andere Materialien ohne zusätzlichen Lückenverlust. Das -14 Material ist ähnlich -2 Material mit einer höheren Permeabilität.

-2, -4, -6 & -7 Materialien: Dies sind die beliebtesten Carbonyleisenmischungen. Sie bieten hohe Q-Werte bis zu 40 MHz und sind am beliebtesten für Amateurfunk und eine Vielzahl anderer Kommunikationsanwendungen. Sie sind auch nützlich für moderate Bandtransformatoren im Frequenzbereich von 200 bis 400 MHz



Kern

Farbe

Außen

mm

Innen

mm

Höhe

mm

Perme-abilität



AL (nH/100Wdgg.2)

AL-Toleranz

Frequenz-bereich

Mass

(approximate)

Product Group

T68-2

Rot

17.53

9.40

4,83

µ 10

57

5%

1-30 MHz

3.8

gramm

RF

RC





AL value (nominal)

5.7 nH/ N²

Density gm/cm3

5.0

Test Winding

N=100, #30 AWG

Frequency

1 MHz

Voltage on Agilent 4284A

1.0 V

Coating Type

Red/Clear Epoxy Paint

Voltage Breakdown (min.)

500 Vrms, 60Hz

Limit

0.1 mA, 5 s

Magnetic

Dimensions

Le Eff. Mag. Path Length (cm)

Ae

Eff. Mag. Cross Section (cm2)

Veff Eff. Core Volume (cm3)

WA - Min. Eff. Window Area

sa - Surface Area

mlt - mean length per turn

4.23 cm

0.179 cm²

0.358 cm³

0.759 cm²

10.6 cm²

2.43 cm



Core Loss & Q

Q Test Winding

N=100, #30 AWG

Q frequenzy

2 MHz

Q min on HP4342A

166

where Bpk expressed in gauss, f expressed in hertz, and:

a=4.00E+09, b=3.00E+08, c=2.70E+06, d=9.60E-16

DC Saturation

HDC

Percent Initial Perm (nom.)

Percent Initial Perm (min.)

200 Oe

95.9%

94.8%

where H expressed in oersteds, and:

a=1.00E-02, b=1.83E-07, c=1.46, d=0.00

Wire Size

AWG

14

16

18

20

22

24

26

28

30

32

34

mm

1.600

1.250

1000

0.800

0.630

0.500

0.400

0.315

0.250

0.200

0.160

Single Layer

Turns

12

15

20

25

32

40

51

64

80

101

126

RDC(Ω)

2.4 m

4.8 m

10.1 m

20.2 m

41.1 m

81.7 m

165.6 m

330.4 m

656.9 m

1.3

2.6

Full Winding

Turns

12

19 m

29

45

69

107

166

256

397

614

950

RDC(Ω)

2.4 m

6.1 m

14.7 m

36.3 m

88.6 m

218.4 m

538.9 m

1.3

3.3

8.0

19.7



T68-3

MATERIAL 3 (Permeabilität 35)

Ein "HP"-gepulvertes Carbonyleisenmaterial mit ausgezeichneter Stabilität und hoher Güte für niedrige Frequenzen um 50 kHz.



Kern

Farbe

Außen

mm

Innen

mm

Höhe

mm

Perme-abilität



AL (nH/100Wdgg.2)

AL-Toleranz

Frequenz-bereich

Mass

(approximate)

Product Group

T68-3

Gray

17.53

9.40

4,83

µ 35

195

10%

0.05.5 MHz

4.9

gramm

RF





AL value (nominal)

19.5 nH/ N²

μi (reference)



µ 35

Density gm/cm3

6.5

Test Winding

N=100, #30 AWG

Frequency

10 kHz

Voltage on Agilent 4284A

0.079 V

Coating Type

Gray/ClearEpoxy Paint

Voltage Breakdown (min.)

500 Vrms, 60Hz

Limit

0.1 mA, 5 s

Magnetic

Dimensions

Le Eff. Mag. Path Length (cm)

Ae

Eff. Mag. Cross Section (cm2)

Veff Eff. Core Volume (cm3)

WA - Min. Eff. Window Area

sa - Surface Area

mlt - mean length per turn

4.23 cm

0.179 cm²

0.358 cm³

0.759 cm²

10.6 cm²

2.43 cm



Core Loss

Bpk

140 G

Frequenz

10 kHz

Core Loss (nominal)

31 mW/cm³

Core Loss (maximum)

36 mW/cm³

where Bpk expressed in gauss, f expressed in hertz, and:

a=1.90E+09, b=2.00E+08, c=9.00E+05, d=4.30E-15

DC Saturation

HDC

Percent Initial Perm (nom.)

Percent Initial Perm (min.)

200 Oe

60.1%

53.7%

where H expressed in oersteds, and:

a=1.00E-02, b=3.49E-06, c=1.43, d=0.00

Wire Size

AWG

14

16

18

20

22

24

26

28

30

32

34

mm

1.600

1.250

1000

0.800

0.630

0.500

0.400

0.315

0.250

0.200

0.160

Single Layer

Turns

12

15

20

25

32

40

51

64

80

101

126

RDC(Ω)

2.4 m

4.8 m

10.1 m

20.2 m

41.1 m

81.7 m

165.6 m

330.4 m

656.9 m

1.3

2.6

Full Winding

Turns

12

19 m

29

45

69

107

166

256

397

614

950

RDC(Ω)

2.4 m

6.1 m

14.7 m

36.3 m

88.6 m

218.4 m

538.9 m

1.3

3.3

8.0

19.7

T68-6

T68-6 MATERIAL 6 (Permeabilität 8)

Ein "SF"-gepulvertes Eisenmaterial, das dem Material "2" sehr ähnelt, aber verbesserte Güte für höhere Frequenzen bis 50 MHz aufweist.




Kern

Farbe

Außen

mm

Innen

mm

Höhe

mm

Perme-abilität



AL (nH/100Wdgg.2)

AL-Toleranz

Frequenz-bereich

Mass

(approximate)

Product Group

T68-6

Gelb

17.53

9.40

4,83

µ 8

47

5%

2-50 MHz

3.8

gramm

RF



AL value (nominal)

4.7 nH/ N²

μi (reference)



µ 8

Density gm/cm3

5.0

Test Winding

N=100, #30 AWG

Frequency

1 MHz

Voltage on Agilent 4284A

1.0 V

Coating Type

Yellow/Clear Epoxy Paint

Voltage Breakdown (min.)

500 Vrms, 60Hz

Limit

0.1 mA, 5 s

Magnetic

Dimensions

Le Eff. Mag. Path Length (cm)

Ae

Eff. Mag. Cross Section (cm2)

Veff Eff. Core Volume (cm3)

WA - Min. Eff. Window Area

sa - Surface Area

mlt - mean length per turn

4.23 cm

0.179 cm²

0.358 cm³

0.759 cm²

10.6 cm²

2.43 cm



Core Loss & Q

Q test winding

N=23, #20 AWG

Q Frequenz

10 MHz

Q min on HP4342A

266

where Bpk expressed in gauss, f expressed in hertz, and:

a=4.00E+09, b=3.00E+08, c=2.70E+06, d=8.90E-16

DC Saturation

HDC

Percent Initial Perm (nom.)

Percent Initial Perm (min.)

200 Oe

98.1%

97.4%

where H expressed in oersteds, and:

a=1.00E-02, b=4.87E-08, c=1.57, d=0.00

Wire Size

AWG

14

16

18

20

22

24

26

28

30

32

34

mm

1.600

1.250

1000

0.800

0.630

0.500

0.400

0.315

0.250

0.200

0.160

Single Layer

Turns

12

15

20

25

32

40

51

64

80

101

126

RDC(Ω)

2.4 m

4.8 m

10.1 m

20.2 m

41.1 m

81.7 m

165.6 m

330.4 m

656.9 m

1.3

2.6

Full Winding

Turns

12

19 m

29

45

69

107

166

256

397

614

950

RDC(Ω)

2.4 m

6.1 m

14.7 m

36.3 m

88.6 m

218.4 m

538.9 m

1.3

3.3

8.0

19.7

T68-10

MATERIAL 10 (Permeabilität 6)

Ein "W"-gepulvertes Carbonyleisenmaterial, das hohe Güte und Stabilität für Frequenzen bis 100 MHz aufweist.

Kern

Farbe

Außen

mm

Innen

mm

Höhe

mm

Perme-abilität



AL (nH/100Wdgg.2)

AL-Toleranz

Frequenz-bereich

Mass

(approximate)

Product Group

T68-10

Schwarz

17.53

9.40

4,83

µ 6

32

5%

10-100 MHz

3.7

gramm

RF





AL value (nominal)

3.2 nH/ N²

μi (reference)

µ 8

Density gm/cm3

5.0

Test Winding

N=100, #30 AWG

Frequency

1 MHz

Voltage on Agilent 4284A

1.0 V

Coating Type

Black/Clear Epoxy Paint

Voltage Breakdown (min.)

500 Vrms, 60Hz

Limit

0.1 mA, 5 s

Magnetic

Dimensions

Le Eff. Mag. Path Length (cm)

Ae

Eff. Mag. Cross Section (cm2)

Veff Eff. Core Volume (cm3)

WA - Min. Eff. Window Area

sa - Surface Area

mlt - mean length per turn

4.23 cm

0.179 cm²

0.358 cm³

0.759 cm²

10.6 cm²

2.43 cm



Core Loss & Q

Q test winding

N=10, #22 AWG

Q Frequenz

18 MHz

Q min on HP4342A

199

where Bpk expressed in gauss, f expressed in hertz, and:

a=4.00E+09, b=3.00E+08, c=2.70E+06, d=8.00E-16

DC Saturation

HDC

Percent Initial Perm (nom.)

Percent Initial Perm (min.)

200 Oe

99.6%

99.4%

where H expressed in oersteds, and:

a=1.00E-02, b=5.54E-09, c=1.69, d=0.00

Wire Size

AWG

14

16

18

20

22

24

26

28

30

32

34

mm

1.600

1.250

1000

0.800

0.630

0.500

0.400

0.315

0.250

0.200

0.160

Single Layer

Turns

12

15

20

25

32

40

51

64

80

101

126

RDC(Ω)

2.4 m

4.8 m

10.1 m

20.2 m

41.1 m

81.7 m

165.6 m

330.4 m

656.9 m

1.3

2.6

Full Winding

Turns

12

19 m

29

45

69

107

166

256

397

614

950

RDC(Ω)

2.4 m

6.1 m

14.7 m

36.3 m

88.6 m

218.4 m

538.9 m

1.3

3.3

8.0

19.7

t68-1

T68-11

MATERIAL 11 (Permeabilität 20)

Ein "C"-gepulvertes Carbonyleisenmaterial, das dem Material '13' sehr ähnelt, aber einen höheren Volumenwiderstand und eine größere Stabilität aufweist.

Kern

Farbe

Außen

mm

Innen

mm

Höhe

mm

Perme-abilität



AL (nH/100Wdgg.2)

AL-Toleranz

Frequenz-bereich

Mass

(approximate)

Product Group

T68-11

Blau

17.53

9.40

4,83

µ 20

115

10%

0.05-5 MHz

4.9

gramm

RF





AL value (nominal)

11.5 nH/ N²

Density gm/cm3

6.4

Test Winding

N=100, #30 AWG

Frequency

10 kHz

Voltage on Agilent 4284A

0.079 V

Coating Type

Blue/Clear Epoxy Paint

Voltage Breakdown (min.)

500 Vrms, 60Hz

Limit

0.1 mA, 5 s

Magnetic

Dimensions

Le Eff. Mag. Path Length (cm)

Ae

Eff. Mag. Cross Section (cm2)

Veff Eff. Core Volume (cm3)

WA - Min. Eff. Window Area

sa - Surface Area

mlt - mean length per turn

4.23 cm

0.179 cm²

0.358 cm³

0.759 cm²

10.6 cm²

2.43 cm



Core Loss

Bpk

140 G

frequenzy

100 kHz

Core Loss (nominal)

31mW/cm³

Core Loss (maximum)

36 mW/cm³

where Bpk expressed in gauss, f expressed in hertz, and:

a=1.90E+09, b=2.00E+08, c=9.00E+05, d=4.30E-15

DC Saturation

HDC

Percent Initial Perm (nom.)

Percent Initial Perm (min.)

200 Oe

82.2%

78.0%

where H expressed in oersteds, and:

a=1.00E-02, b=1.14E-06, c=1.43, d=0.00

Wire Size

AWG

14

16

18

20

22

24

26

28

30

32

34

mm

1.600

1.250

1000

0.800

0.630

0.500

0.400

0.315

0.250

0.200

0.160

Single Layer

Turns

12

15

20

25

32

40

51

64

80

101

126

RDC(Ω)

2.4 m

4.8 m

10.1 m

20.2 m

41.1 m

81.7 m

165.6 m

330.4 m

656.9 m

1.3

2.6

Full Winding

Turns

12

19 m

29

45

69

107

166

256

397

614

950

RDC(Ω)

2.4 m

6.1 m

14.7 m

36.3 m

88.6 m

218.4 m

538.9 m

1.3

3.3

8.0

19.7
